技術參數

Specification

        型號 Model

CA6140

CA6240

床身上大工件回轉直徑 Max. Swing  over bed

400mm

刀架上大工件回轉直徑 Max. swing  over carriage

210mm

馬鞍槽大工件回轉直徑 Max.swing in gap

--------

630mm

馬鞍槽有效長度Effective gap length

--------

210mm

大工件長度 Max.length of workpiece

750mm/1000mm/1500mm/2000mm/3000mm

床身寬度Width of bed

400mm

刀桿截面Section of turning tool

25 x 25

主電機功率 Motor Power

7.5kw（10HP)

 主軸

Spindle

主軸轉速范圍Spindle speed

10-1400rpm/16-1400rpm(24 steps)

主軸內孔Hole through spindle

52mm.(80mm).(105mm)

主軸錐度 Spindle taper

莫氏NO.6(MT6)( Φ90 1:20){ Φ113 1:20}

進給

Feed

進給數量 Number of feeds

64kinds for each

公制螺紋Range of metric threads(kinds)

(1-192mm) 44kinds

英制螺紋Range of inch threads(kinds)

(2-24tpi)21kinds

模數螺紋Range of module threads(kinds)

0.25-48( Module 39 kinds)

徑節螺紋 Range of pitch threads(kinds)

1-96DP(37 kinds)

 尾座

Tailstock

尾座套筒大行程 Max. Tailstock travel

 150mm

尾座直徑Tailstock spindle diameter

75mm

尾座主軸孔錐度Taper of Tailstock

NO.5 (MT5）

包裝尺寸

Packing Size

750mm/1000mm/1500mm/2000mm/3000mm

2550/2700/3200/3700/4850/x 1140 x 1750mm

 重量

weight

  長度 Length

毛重 G.W KGS

凈重N.W.KGS

750mm

2100

1900

1000mm

2190

2070

1500mm

2350

2220

2000mm

2720

2570

3000mm

3300

3200
